Spirax Sarco SV60/SV604DS/SV607DS Safety Valves

Description

Spirax Sarco SV60 full stroke safety valves with flange connection for applications in steam, non-chemical industrial gases and water systems.Models SV604 and SV607.

Available Models

Available types	SKU
DN20/32 SV607 DS	tba
DN25/40 SV607 DS	tba
DN32/50 SV607 DS	tba
DN40/65 SV607 DS	tba
DN50/80 SV607 DS	tba
DN65/100 SV607 DS	tba
DN80/125 SV607 DS	tba
DN100/150 SV607 DS	tba
DN125/200 SV607 DS	tba
DN150/250 SV607 DS	tba

Certificates, standards and accreditations

• Has certificates such as EN10204 2.2 and EN10204 3.1.
• Conforms to ANSI/API STD 527 - 1992, 97/23/EC 4 2, PED, LR TA96 - 01/00125E2 and other standards and certifications, of which the SV604 also conforms to PN AD - Merkblatt A2, AD - Merkblatt A4, TRD 421, Vd TUA 100,100/4.

Caliber and connection

The caliber covers DN20, DN25, DN32, DN40, DN50, DN65, DN80, DN100, DN125, DN150, SV607 has PN16 (DN65 - DN150) and other connections, SV604 has PN40, PN16 and other connections, and the standard of connection is in accordance with EN 1092-1:2002.

Weight (approximate)

There are variations in size and weight for different calibers, for example:

Caliber inlet/outlet	Weight (SV604)	Weight (SV607)
DN20 - DN32	10.5 kg	10.5 kg
DN25 - DN40	12.5 kg	11.5 kg
DN32 - DN50	16.0 kg	15.0 kg
DN40 - DN65	18.0 kg	18.0 kg
DN50 - DN80	20.0 kg	22.0 kg
DN65 - DN100	40.0 kg	38.0 kg
DN80 - DN125	56.0 kg	53.0 kg
DN100 - DN150	77.0 kg	75.0 kg
DN125 - DN200	120.0 kg	115.0 kg
DN150 - DN250	190.0 kg	180.0 kg

Security information, installation and maintenance

Refer to the Installation and Maintenance Guide (IM - P13701) supplied with the product for details and make sure that the centerline of the spring chamber of the safety valve is vertically upward during installation.

How to Order

Example: 1 - Spirax Sarco SV604DS DN20 PN40 inlet flange connection safety valve, set pressure 6 bar g.
