Spirax Sarco MV11/MV14 Solenoid Valve

Description

The Spirax Sarco MV solenoid valve is a pilot operated solenoid valve with NAMUR connection, primarily used with the BVA300 pneumatic actuator.

operating pressure	2-8 bar
Interface Size	G 1/4
electrical connection	DIN EN 175301-803 FormB
flow	Fixed 2-position tee / 2-position 5-position
Ambient / Fluid Temperature	-15 - +50 °C (air supply must be dry to avoid freezing at temperatures below 2 °C)
Kv	1.2
input voltage	24VDC 230VAC
power (output)	1.8W(24VDC) 4.3W(230VAC)
protection class	IP65

valve body	aluminum (chemistry)
seals	NBR (Special Nitrile Rubber)
